Steel systems specialist, Schueco Jansen, has introduced a range of steel windows and doors that can achieve ultra-low ‘U’ values thanks to a newly-developed isolator made from glass fibre-reinforced polyurethane.
The thermal efficiency of the new Janisol HI systems is matched by high structural strength, making them ideal for a wide variety of applications.
The Janisol HI steel window is available with turn-tilt and side-hung opening vents or fixed glazing, achieving impressive Uw values of 0.8 W/m2K and 0.69 W/m2K respectively. The dimensions of a standard 90mm deep opening vent can be up to 2800mm in height with a total weight of up to 180kg.
Different infill unit thicknesses up to 67mm allow the use of triple-glazing and burglar-resistant glass, while its slimline external face-width and a wide variety of coating options mean that a Janisol HI steel window can meet the highest possible specification for both functionality and design.
The Janisol HI steel door combines mechanical stability with high thermal insulation properties in one single steel profile system, so it is especially well-suited for locations such as heavily-trafficked areas in busy public buildings.
As with the Janisol HI window, the Janisol HI steel door benefits from the glass fibre-reinforced polyurethane isolator, achieving excellent UD values of up to 1.0 W/m2K. With a basic depth of 80mm, infill unit thicknesses of up to 57mm can be used with triple-glazing and burglar-resistant glass.
A comprehensive, co-ordinated range of fittings and accessories combined with a variety of thresholds of differing heights, make the Janisol HI steel door the perfect solution for commercial offices, leisure centres, shopping centres and similar spaces accessed by the public.
